Vaxis ATOM 600HDMI Kit

339.16

Vaxis ATOM 600HDMI Kit – Includes 1x TX, 1x RX (P/N VA21-600-TR01) vaxis-atom-600hdmi-kit-va21-600-tr01 / VA21-600-TR01

Compare
Category:

OVERVIEW
Vaxis Atom 600 HDMI
Keep Humble More Muscle
Multiple Ports
Dual HDMI ports, support HDMI loop out.
Dual Power Supply Options
NP-F97- Battery + USB Type-C
Dual Cavs Antenna
2.4 and 5.8 dual-frequency compatible. Stronger signal, faster tranfer rate.
Multiple Connection Methods
Compatible With Atom Ecosystem
Trigger Record
When used with Atom A5, it can directly trigger the synchronous recording function of Atom 5.
APP Monitoring
Supports monitoring on mobile phone, iPad and monitor simultaneously. Mobile phone instantly turns into a monitor.
One Camera To Five Monitor Screens
One transmitter can connct to two recievers, plus three mobbile deviices simultaneoulsly
INCLUDED IN BOX
1x ATOM 600 HDMI Kit
1x Instruction Card

Vaxis Atom 600 HDMI

Keep Humble More Muscle

Multiple Ports

Dual HDMI ports, support HDMI loop out.

Dual Power Supply Options

NP-F97- Battery + USB Type-C

Dual Cavs Antenna

2.4 and 5.8 dual-frequency compatible. Stronger signal, faster tranfer rate.

Multiple Connection Methods

Compatible With Atom Ecosystem

Trigger Record

When used with Atom A5, it can directly trigger the synchronous recording function of Atom 5.

APP Monitoring

Supports monitoring on mobile phone, iPad and monitor simultaneously. Mobile phone instantly turns into a monitor.

One Camera To Five Monitor Screens

One transmitter can connct to two recievers, plus three mobbile deviices simultaneoulsly

TX:
Interface HDMI input/HDMI output
Voltage 5V DC
Power <5w HDMI Input Video Format 720P@50/60Hz 1080I@50/60Hz 1080P@24/25/30/50/60/Hz HDMI Output Video Format / SDI Input Video Format 720P@50/60Hz 1080I@50/59.94/60Hz 1080P@23.98/24/25/29.97/30/50/59.94/60Hz 1080PSF23.98/24//25/29.97/30Hz SDI Output Video Format / Weight 150g Dimensions 91 x 63.5 x 26 mm Frequency 5GHz Transmission Power 17dbm Delay 80ms Rx Sensitivity -80dbm RX: Interface HDMI output*2 Voltage 5V DC Power <3w HDMI Input Video Format / HDMI Output Video Format 720P@50/60Hz 1080I@50/60Hz 1080P@24/25/30/50/60/Hz SDI Input Video Format / SDI Output Video Format 720P@50/60Hz 1080I@50/60Hz 1080P@24/25/30/50/60/Hz Weight 150g Dimensions 91 x 63.5 x 26 mm Frequency 5GHz Transmission Power 17dbm Delay 80ms Rx Sensitivity -80dbm 150m Transmission Range Dual Cavs Antenna Fit In With Atom Ecosystem Ultra Low Latency Multiple Ports Trigger Record 4 Inches - Lightweight and Portable 3.5w Fanless Design
