Miller 1511 DS10 Solo DV System

OVERVIEW
The SOLO 10 system combines the ultralight, ultra rigid carbon fibre SOLO tripod with the versatile DS10 75mm ball levelling head & selectable counterbalance. With a height range from 8″ all the way up to 63″ SOLO 10 suits 5lb – 10lb MiniDV and DVCAM payloads from barebones to fully stacked PD150 or Canon XL-1.

DS10 Fluid Head (182)
The DS10 fluid head boosts similar physical appearance and features as the DS5 fluid head. However, it offers 2 selectable counterbalance positions for MiniDV/DVCAM/HDV camcorders with larger lens/battery from 2.5kg to 5kg. Improved pan and tilt drag adjustments provide a friction boost to the true fluid action.

Solo DV 2 Stage 75mm Carbon Fibre Tripod (1501)
The 2-Stage telescoping SOLO DV carbon fibre tripod is designed for the single operator: quickly and securely setting up to 63″ (161cm), packing down to a compact 27″ (70cm) for transport; and hitting a low 9″ (23cm). Selectable leg angle locks ensure rapid stabilisation at any height,…

SUMMARY
Tripod Head Type: Fluid Head
Max Payload: 5kg
Max Height Group: 65-70 inch
Min Height Group: 10-20 inch
Leg Section: 3 Section
Spreader Type: No Spreader
Head Fitting: 75mm
Material: Carbon Fibre
Type: Video
INCLUDED IN BOX
1x DS10 Fluid Head
1x Solo 75 2-stage tripod (carbon fibre)
1x Pan Handle – fixed with clamp
1x Solo Shoulder Strap (Aircell)
1x Solo 75 2-stage tripod bag

About The Miller 1511 DS10 Solo DV System
The SOLO 10 system combines the ultralight, ultra rigid carbon fibre SOLO tripod with the versatile DS10 75mm ball levelling head & selectable counterbalance. With a height range from 8″ all the way up to 63″ SOLO 10 suits 5lb – 10lb MiniDV and DVCAM payloads from barebones to fully stacked PD150 or Canon XL-1.

DS10 Fluid Head (182)
The DS10 fluid head boosts similar physical appearance and features as the DS5 fluid head. However, it offers 2 selectable counterbalance positions for MiniDV/DVCAM/HDV camcorders with larger lens/battery from 2.5kg to 5kg. Improved pan and tilt drag adjustments provide a friction boost to the true fluid action.

Solo DV 2 Stage 75mm Carbon Fibre Tripod (1501)
The 2-Stage telescoping SOLO DV carbon fibre tripod is designed for the single operator: quickly and securely setting up to 63″ (161cm), packing down to a compact 27″ (70cm) for transport; and hitting a low 9″ (23cm). Selectable leg angle locks ensure rapid stabilisation at any height, while the 75mm diecast alloy bowl and fluid head bubble level offers quick levelling, optimum torsional rigidity and durability under extreme field conditions.

Fixed Length Pan Handle for DS5/10/20 Fluid Heads (680)
Fixed length pan handle supplied with grey handle carrier to suit DS5, DS10 and DS20 Fluid Heads

Solo DV Strap (1520)
The ergonomic and air-cell padded 1520 SOLO Shoulder Strap can be fitted to all tripods and softcases in the Miller SOLO range. Made from weatherproof cordura and nylon materials, with anti-corrosive buckles and safety spring latches that can attach to all 75mm and 100mm SOLO tripods.

Solo DV Softcase (1518)
The Solo DV Softcase is a compact and comfortable carrying solution made from weatherproof cordura construction. Weighing only 0.65kg and a transport length of 850mm this softcase is the perfect travelling companion.

Material Carbon Fibre
Construction 2-Stage
Maximum Height 1751 mm (68.9 in)
Minimum Height 371 mm (14.6 in)
Mounting Standard 75mm ball levelling
Payload Capacity 5.00 kg (11 lbs)
Payload Range 2.5 to 5 kg
Transport Length 831 mm (32.7 in)
Weight 4.5 kg (10.0 lbs)

Flick-of-a-switch 5-10lb CB selection
True fluid pan and tilt drag
75mm ball levelling
Quick Release sliding plate
2-Stage Carbon/magnesium telescoping
