OVERVIEW
The BC-15C/BC-15CN is a compact camera designed to be mounted anywhere without compromising on quality. It features a 1/2.3” 4K CMOS sensor that captures high-quality images and comes with interchangeable CS mount lenses, allowing for a wide range of visual expression. The camera also supports the SRT streaming protocol, providing a more reliable streaming experience even in unstable network environments. It also has H.264/H.265 video compression for dual streaming, a built-in tally light, and power over Ethernet for easy installation. The physical buttons on the rear panel make camera setup and adjustments easy, and it can be mounted using the 1/4” screw holes.
The BC-15C/BC-15CN is a professional camera that is compatible with Datavideo’s dvCloud service, allowing for simultaneous streaming to multiple platforms and recording in h.264 format. The camera can be controlled and monitored using the dedicated mobile app, providing easy access to video and audio settings. With its compact design, high-quality features, and seamless compatibility with dvCloud, the BC-15C/BC-15CN is an ideal choice for capturing eSport applications and a wide range of live streaming events.
SUMMARY
Weight: 0-2kg
INCLUDED IN BOX
1 x BC-15C Main Unit
1 x CS-C Lens adaptor ring
1 x DC 12V power adaptor
About The Datavideo BC-15C – 4K CS Mount POV Camera
Designed to be Compact
Small box design makes it flexible to be mounted anywhere. Though it is compact, it doesn’t compromise on quality. 1/2.3” 4K CMOS sensor captures high quality images and incredible details of the subject.
Interchangeable CS Mount Lenses
User can install a CS Mount camera lens to the BC-15C/BC-15CN, or use a C Mount camera lens with the bundled 5mm CS-C camera lens adapter ring. User can have a wide range of visual expression by using different lenses for the BC-15C/ BC-15CN.
* Lens is NOT included with the BC-15C/BC- 15CN package.
1/2.3” CMOS Sensor with 4K 50/60p output
BC-15 series is one of the best cameras for capturing eSport applications with the wide angle lens. While changing back to the standard lens, it will fulfill the other wide range applications.
Support SRT streaming protocol, no need to worry about unreliable network environment
Many broadcasters have experienced pixelated video during live streaming, often due to unstable network environments caused by bandwidth volatility.
Streaming RTMP over unreliable, low-bandwidth networks can cause issues. With dvCloud, you can now replace the RTMP protocol with SRT, which will fix most streaming issues you may have. SRT is better than RTMP because it handles problematic networks more efficiently.
It requires less bandwidth, and it solves data errors faster. As a result, your viewers will experience a better stream, with less buffering and pixelization.
H.264/H.265 video compression for dual streaming
During video production, you can stream simultaneously to two live streaming platforms such as Facebook, Youtube and Twitch. With Datavideo dvCloud, you can stream to 25 live streaming platforms at the same time and automatically back up your video files on the cloud server.
Built-in Tally Light
Built-in tally lights make it easier for the talent to know which camera is live during a multi-camera live production.
Power over Ethernet
The BC-15C supports PoE for easy installation. No need to find local power outlets or hire an electrician to install outlets wherever you want to mount your camera. Simply run a single CAT 6 cable to power your BC-15C.
Physical Buttons Make Camera Setup Very Easy
When the camera is set up, there is no need to use an additional remote controller. The physical buttons on the rear panel of the BC-15C make it very easy to adjust settings.
1/4” Screw Hole for Mounting
Changing the camera angle is easy with the three 1/4” screw holes on the BC-15C. It gives you the flexibility of mounting it anywhere.
Professional APP
Camera – The APP will automatically scan the network for connected DVIP devices. All detected BC- 15P devices will be listed for selection.
Encoder – Provides H.265/264 video coding standard or high efficiency video coding for various major streaming platforms.
Streaming – The main encoder uses the latest SRT protocol as well as the standard RTMP/RTMPS protocols. The multiview screen is streamed to the APP using the sub encoder.
Audio – Professional audio settings allow you to physically configure the audio input. You can make selection of the audio input type (Line/ MIC), audio type (mono/stereo) and audio standard (SMPTE/EBU).
Configuring Live Video on the Mobile Phone
You can adjust the video settings on the mobile phone and use the sub encoder to preview the video as you make changes to the settings. You can also monitor critical camera settings such as HDMI output resolution,camera name, and stream status.
Seamlessly Compatible with dvCloud
Get the most out of your streaming hardware using dvCloud. The BC-15C is seamlessly compatible with Datavideo’s dvCloud service.
This subscription service give you the possibility of sending your stream to multiple destinations at the same time without having to have multiple hardware encoders.
You can also record your production on the dvCloud platform in h.264 format. After recording you can directly use this recording to upload it to your favourite content platform.
Video format/Resolution 2160p 60/59.94/50/30/29.97/25
1080p 60/59.94/50/30/29.97/25
Image Sensor 1/2.3″ CMOS
Effective Pixels (approx.) 12.3Mega Pixels
S/N Ratio 50 dB
Min. Illumination 0.5Lux (F1.0, AGC ON)
* depend on Lens
Electronic Shutter 1/25(1/30), 1/50(1/60), 1/75(1/90), 1/100(1/120), 1/125(1/150), 1/150(1/180),
1/200(1/210), 1/500(1/600), 1/1000(1/1200), 1/2000(1/2400), 1/4000(1/4800), 1/8000(1/9000) sec
Zoom Ratio 2x Digital Zoom
Optical Zoom depend on lens =
Gamma Control Standard / Mode1 / Mode2 / Mode3
Iris Control DC IRIS supported
* depend on Lens
Digital Noise Reductions 2D/3D
On-Screen Display (OSD) English/Simplified Chinese/Traditional Chinese
White Balance Auto, Indoor, Outdoor, OnePush, Colour Temp., R/B Gain, Lock
AGC / Gain Control Auto(AGC) / Manual / Lock
(Follow Exposure Mode)
HDR/WDR WDR
Mirror / Flip Image Yes
Focus Mode Full Manual
Panning / Tilting Range —-
Panning / Tilting Speed —-
Preset —-
Focal Length * depend on Lens
Field of View (Horizontal, Wide) * depend on Lens
Image Compensation Auto
Video Output HDMI 2.0 x1
RJ45 x1
Audio Input 3.5mm Line in/Mic in (Stereo)
Tally LED Dual colour (Red, Green)
Lens Filter IR cut built-in
Control Protocol DVIP
Remote Control Interface RJ-45: for IP control (DVIP)
Video Compression Format H.264, H.265
Audio Compression Format AAC
Audio Bitrate 128Kbps
HD IP Interface 10/100/1000M
Streaming Protocols RTMP(S), SRT
First Stream Supported Resolution 1920×1080
1280×720
1024×576
960×540
640×480
640×360
Video Bitrate 1Mbps ~ 7Mbps
Video Bitrate Mode VBR, CBR
Encoding Frame rate 50Hz: 1-50fps
60Hz: 1-60fps
POE IEEE802.3af
F/W Update Ethernet
IR Control —-
Camera Control Unit RMC-300 series/BC View Assist APP
Tripod Mount 1/4-20 UNC
Colour Black
Dimension (LxWxH) 77mm (W) x 82mm (D) x 78mm (H)
Weight 204 g
Operating Temp. Range 0~40 °C
Power DC 12V 9W
